Our Magnets are widely used in various Industrial Motors (Linear Motor / Servo motor / Robot Joint Motor / Elevator Motor ) , Automobile, Sensors, Medical Equipment, Microwave Devices, Communications, Instruments, Meters, various Magnetic Transmission Devices, Magnetic Processors, Magnetic Cranes and other fields.
Here are some customers who use our Magnets.
DATOYO can supply small ferrite magnet like 0.8 x 0.8 x 0.5mm with tolerance +/-0.03 and Br: 420 mT , bHc: 225 kA/m, iHc: 230 kA/m, BHmax: 34 kJ/m³.
The application of small ferrite magnet are Sensors, Relay, etc.
Special magnet with Multipole Magnetization.
Magnetic properties: Br: 280 mT , bHc: 175 kA/m, iHc: 220 kA/m, BHmax: 15 kJ/m³
The application is Auto Gearbox.
Ferrite mixed Ndfeb and Multi-poles magneitzed.
Magnetic properties: Br >=300 mT , bHc > = 400 kA/m, iHc >= 480 kA/m, BHmax >= 20 kJ/m³
It wildely used on Sensor of Auto Brake.
Magnetic coupling is a new kind of coupling, which connects motor and machine by permanent magnetic force. They work in the sealless magnetic drive pumps, which transporting volatile, flammable, explosive and toxic solutions with no leakage. The appearance of Magnetic coupling solved thoroughly the leak problems existed in dynamic sealing of certain mechanical devices.
Magnetic coupling are widely used in various industries and fields, such as chemical, papermaking, foodstuff, pharmacy, and so on. Magnetic coulpling consist of external rotor,internal rotor and isolating cover.
The coreless linear motor is used in high-speed and high-precision applications and runs under high thrust without thrust ripple.
