1: High performance, isotropic.
2: Magnetization can be in any direction, suitable for radial and axial multipolar magnetization.
3: Exact size.
4: Versatile shapes and specification.
5: Advanced surface treatment technology, effectively protect.
6: Integrated forming.
1) Magnetic stators for fractional horsepower DC motors
2) Muti-pole magnetic rotors for brushless DC and stepper motors
3) Magnetic actuators for a diverse range of magnetic switches and solenoids
4) Sensors for automotive and industrial applications
| Grade | Br | Hcj | Hcb | (BH)max | ||||
| T | kGs | KA/m | kOe | KA/m | kOe | KJ/m3 | MGOe | |
| DSNP-6 | 0.46-0.54 | 4.6-5.4 | 640-720 | 8.0-9.0 | 272-320 | 3.4-4.0 | 32-48 | 4.0-6.0 |
| DSNP-8 | 0.54-0.64 | 5.4-6.4 | 640-920 | 8.0-11.5 | 320-440 | 4.0-5.5 | 48-64 | 6.0-8.0 |
| DSNP-8H | 0.58-0.62 | 5.8-6.2 | 1000-1400 | 12.5-17.5 | 400-440 | 5.0-5.5 | 56-72 | 7.0-9.0 |
| DSNP-10 | 0.62-0.72 | 6.2-7.2 | 640-920 | 8.0-11.5 | 360-460 | 4.5-5.8 | 64-80 | 8.0-10.0 |
| DSNP-12 | 0.69-0.76 | 6.9-7.6 | 700-880 | 8.8-11.0 | 400-480 | 5.0-6.0 | 80-96 | 10.0-12.0 |
